คุณสมบัติ | รายละเอียด |
|---|---|
| Coil Voltage | 24V dc |
| Coil Power | 7W |
| Coil Resistance | 19.9 Ω |
| Contact Configuration | SPST |
| Number of Poles | 1 |
| Switching Current | 1500A |
| Maximum Switching Current AC | 1500 A |
| Maximum Switching Current DC | 1000 mA |
| Maximum Switching Voltage DC | 24V dc |
| Maximum Switching Voltage AC | 500V ac |
| Mounting Type | Flange Mount |
| Terminal Type | Screw |
| Standards Met | RoHS Compliant |
| Contact Material | Silver Alloy |
| Maximum Operating Temperature | +120°C |
| Maximum Switching Power DC | 7000mW |
| Length | 37mm |
| Depth | 60mm |
| Height | 33mm |
| Isolation Coil To Contact | 500V rms |
| Series | BDS-A |
| Minimum Operating Temperature | -40°C |
1-1393315-1
5-1618241-7
6-1393292-3
